2-Section Ultrasound Table

2 Section Oakworks Ultrasound Table

The basic ultrasound table by Oakworks is a great medical table choice for existing diagnostic imaging clinic or a new diagnostic imaging center. The ultrasound table comes with a standard 2-section tabletop, which can be controlled by an electric fowler, allowing for optimal patient positioning.



Features

- Ergonomic 2 section top table with electrically adjustable fowler and 12 optional features to upgrade overall functionality
- Designed  by leading Ergonomic Specialists and exceeds industry standards for sonography
- Industry leading 3 year warranty
- 21 beautiful fabric colors available
- Dynamic 22" to 38" adjustable height range for safe wheelchair transfer and ergonomic working heights
- 550 lb bariatric rated lift and load capacity
- Twin tower design for added strength and rigidity
- Sleek base design promotes unobstructed compatibility with ultrasound equipment ensuring better ergonomic conditions for the sonographer
- Super comfortable 3" padding system
- Trendelenburg and Reverse Trendelenburg



Optional Features

- Patient Lift Compatible Base
- Foot Control switch
- Central Base Locking System
- Adjustable access back support (Left or Right)
- Sliding Cardio Panel - Electric 30"W (left side only)
- Sliding Cardio Panel - Manual 30"W (left side only)
- Side Rails(2)

Specs

Patient Weight Capacity: 550 lbs. (272 kg.)
Height Range: 22" - 38" (56-97 cm)
Width: 27" (69 cm) or 30" (76 cm)
Length: Fowler - 34" (86 cm), Seat - 38" (97 cm)
Trendelenburg/Reverse Tilt: ±15°
Standard Controls: 3 motion hand
Padding: 3" (8cm) multi-layer
21 Upholstery colours available
Warranty: 3 years parts, 2 years labor
Certifications: FDA listed, cETL approved, CE marked
Included Features: Electric Fowler, Hand control, 4" Locking Casters, Paper roll holder
