Vascular Table

Vascular Table

The Vascular Table by Oakworks offers maximum versatility and patient comfort and safety. The medical exam table is designed for the field of medical imaging, particularly for ultrasound applications.



Features

- Dual towers & electric fowler makes 70° reverse Trendelenburg a reality.
- Effective standing and full weight bearing footboards.
- No more sitting on the floor to scan.
- Split drop footboard makes non-weight bearing scans safe and easy.
- Elevate the upright table to reduce/prevent technologist bending to reach lower extremity veins.
- Headrest and pad for carotid studies provide comfort and access for patient and sonographer



Optional features

Patient Lift Compatible Base
Foot Controls
Central Base Locking System
Adjustable access back support (Left or Right)
Sliding Cardio Panel - Manual 30"W + left side only


Specs

-Patient Weight Capacity: 550 lbs. (272 kg.)
-Height Range: 23" - 40" (58-102 cm)
-Width: 27" (69 cm) or 30" (76 cm)
-Length: Fowler - 34" (86 cm), Seat - 38" (97 cm)
-Side Rails(2)
-Trendelenburg: 15°
-Reverse Trendelenburg: up to 70°
-Standard Controls: 4 motion hand
- Padding: 3" (8cm) multi-layer
- 21 Upholstery colours available
-Warranty: 3 years parts, 2 years labour
-Certifications: FDA listed, cETL approved, CE marked

Included Features: Electric Fowler, Integrated Foot Board (split, drop away), Patient Restraint Strap, Side Rails(2), Hand control(all movements), 4" Locking Casters, Paper roll holder
